Lte Interview Questions and Answers

Q1. What is LTE?

Ans: LTEⁱ (Long Term Evolution) is initiated by 3GPPⁱ to improve the mobile phone standard to cope with future technology evolutions and needs.

Q2. What speed LTE offers?

Ans: LTE provides downlink peak rates of at least 100Mbit/s, 50 Mbit/s in the uplink and RAN (Radio Access Network) round-trip times of less than 10 ms.

Q3. What is goal of LTE?

Ans: The goals for LTE include improving spectral efficiency, lowering costs, improving services, making use of new spectrum and reformed spectrum opportunities, and better integration with other open standards.

Q4. What is LTE Advanced?

Ans: LTE standards are in matured state now with release 8 frozen. While LTE Advanced is still under works. Often the LTE standard is seen as 4G standard which is not true. 3.9G is more acceptable for LTE. So why it is not 4G? Answer is quite simple - LTE does not fulfill all requirements of ITU 4G definition.

Brief History of LTE Advanced: The ITU has introduced the term IMT Advanced to identify mobile systems whose capabilities go beyond those of IMT 2000. The IMT Advanced systems shall provide best-in-class performance attributes such as peak and sustained data rates and corresponding spectral efficiencies, capacity, latency, overall network complexity and quality-of-service management. The new capabilities of these IMT-Advanced systems are envisaged to handle a wide range of supported data rates with target peak data rates of up to approximately 100 Mbit/s for high mobility and up to approximately 1 Gbit/s for low mobility.

Q5. What is EUTRAN?

Ans: The E-UTRAN (Evolved UTRAN) consists of eNBs, providing the E-UTRA user plane (PDCP/RLC/MAC/PHY) and control plane (RRC) protocol terminations towards the UE. The eNBs are interconnected with each other by means of the X2 interface. The eNBs are also connected by means of the S1 interface to the EPC (Evolved Packet Core), more specifically to the MME (Mobility Management Entity) by means of the S1-MME and to the Serving Gateway (S-GW) by means of the S1-U.

Q6. What are LTE protocols & specifications?

Ans:

• Air Interface Physical Layer
• GPRS Tunnelling Protocol User Plane (GTP-U)
• GTP-U Transport
• Medium Access Control (MAC)
• Non-Access-Stratum (NAS) Protocol
• Packet Data Convergence Protocol (PDCP)
• Radio Link Control (RLC)
• Radio Resource Control (RRC)
• S1 Application Protocol (S1AP)
• S1 layer 1
• S1 Signalling Transport
• X2 Application Protocol (X2AP)
• X2 layer 1
• X2 Signalling Transport

Q7. What are LTE Interfaces?

Ans: The following are LTE Interfaces : (Ref: TS 23.401 v 841)

• S1-MME :- Reference point for the control plane protocol between E-UTRAN and MME.
• S1-U:- Reference point between E-UTRAN and Serving GW for the per bearer user plane tunnelling and inter eNodeB path switching during handover.
• S3:- It enables user and bearer information exchange for inter 3GPP access network mobility in idle and/or active state.
• S4:- It provides related control and mobility support between GPRS Core and the 3GPP Anchor function of Serving GW. In addition, if Direct Tunnel is not established, it provides the user plane tunnelling.
• S5:- It provides user plane tunnelling and tunnel management between Serving GW and PDN GW. It is used for Serving GW relocation due to UE mobility and if the Serving GW needs to connect to a non-collocated PDN GW for the required PDN connectivity.
• S6a:- It enables transfer of subscription and authentication data for authenticating/authorizing user access to the evolved system (AAA interface) between MME and HSS.
• Gx:- It provides transfer of (QoS) policy and charging rules from PCRF to Policy and Charging Enforcement Function (PCEF) in the PDN GW.
• S8:- Inter-PLMN reference point providing user and control plane between the Serving GW in the VPLMN and the PDN GW in the HPLMN. S8 is the inter PLMN variant of S5.
• S9:- It provides transfer of (QoS) policy and charging control information between the Home PCRF and the Visited PCRF in order to support local breakout function.
• S10:- Reference point between MMEs for MME relocation and MME to MME information transfer.
• S11:- Reference point between MME and Serving GW.
• S12:- Reference point between UTRAN and Serving GW for user plane tunnelling when Direct Tunnel is established. It is based on the Iu-u/Gn-u reference point using the GTP-U protocol as defined between SGSN and UTRAN or respectively between SGSN and GGSN. Usage of S12 is an operator configuration option.
• S13:- It enables UE identity check procedure between MME and EIR.
• SGi:- It is the reference point between the PDN GW and the packet data network. Packet data network may be an operator external public or private packet data network or an intra operator packet data network, e.g. for provision of IMS services. This reference point corresponds to Gi for 3GPP accesses.
• Rx:- The Rx reference point resides between the AF and the PCRF in the TS 23.203.
• SBc:- Reference point between CBC and MME for warning message delivery and control functions.

Q8. What is CS Fallback in LTE?

Ans: LTE technology supports packet based services only, however 3GPP does specifies fallback for circuit switched services as well. To achieve this LTE architecture and network nodes require additional functionality, this blog is an attempt to provide overview for same.

In LTE architecture, the circuit switched (CS) fallback in EPS enables the provisioning of voice and traditional CS-domain services (e.g. CS UDI video/ SMS/ LCS/ USSD). To provide these services LTE reuses CS infrastructure when the UE is served by E UTRAN.

Q9. Why sub carrier spacing is more for wifi than LTE

Ans: I think LTE support high mobility support compare to WiFi, which means LTE technology support you service even when you are moving with very high speed of the order of around 300Km/h. as we know as the high the mobility of channel less will be the coherence time ( high doppler shift), due to which we have keep sub-carrier spacing small for LTE.

Q10. Difference between OFDM and OFDMA

Ans: Basically while asking this question they know that guy must be knowing OFDM but can he differentiate OFDMA.

So without giving details of OFDM (go to my webpage for details) the OFDMA is multiple access technique in which individual users are assigned subsets of available subcarriers within one OFDM symbol and hence multiple users can access the link at the same time.

Q11. What are LTE Network elements?

Ans:

eNB
eNB interfaces with the UE and hosts the PHYsical (PHY), Medium Access
Control (MAC), Radio Link Control (RLC), and Packet Data Control
Protocol (PDCP) layers. It also hosts Radio Resource Control (RRC)
functionality corresponding to the control plane. It performs many
functions including radio resource management, admission control,
scheduling, enforcement of negotiated UL QoS, cell information
broadcast, ciphering/deciphering of user and control plane data, and
compression/decompression of DL/UL user plane packet headers.

Mobility Management Entity
manages and stores UE context (for idle state: UE/user identities, UE mobility state, user security parameters). It generates temporary identities and allocates them to UEs. It checks the authorization whether the UE may camp on the TA or on the PLMN. It also authenticates the user.

Serving Gateway
The SGW routes and forwards user data packets, while also acting as the mobility anchor for the user plane during inter-eNB handovers and as the anchor for mobility between LTE and other 3GPP technologies (terminating S4 interface and relaying the traffic between 2G/3G systems and PDN GW).

Packet Data Network Gateway
The PDN GW provides connectivity to the UE to external packet data networks by being the point of exit and entry of traffic for the UE. A UE may have simultaneous connectivity with more than one PDN GW for accessing multiple PDNs. The PDN GW performs policy enforcement, packet filtering for each user, charging support, lawful Interception
and packet screening.

Q12. How does measurements work in LTE?

Ans: In LTE E-UTRAN measurements to be performed by a UE for mobility are classified as below

• Intra-frequency E-UTRAN measurements
• Inter-frequency E-UTRAN measurements
• Inter-RAT measurements for UTRAN and GERAN
• Inter-RAT measurements of CDMA2000 HRPD or 1xRTT frequencies

Q13. Advantage and Disadvantage of OFDMA over OFDM

Ans: ADVANTAGE:

• Allow simultaneous low data rate for several carriers.
• Bursty transmission is minimised
• Contention based multiple access is simplified
• Provide frequency diversity by spreading the carrier across complete available spectrum
• Interference within cell can be minimised on an average by allocating carrier based on cyclic permutation within band

DISADVANTAGE:

• Frequency and phase error sensitivity
• diversity gain is not achieved if only few carriers are allocated or same carrier allocated again.
• Fast feedback based mechanism required which is more complex
• Does not suit to asynch bursty data communication.

Q14. What is VoLGA?

Ans: VoLGA stands for "Voice over LTE via Generic Access". The VoLGA service resembles the 3GPP Generic Access Network (GAN). GAN provides a controller node - the GAN controller (GANC) - inserted between the IP access network (i.e., the EPS) and the 3GPP core network.
The GAN provides an overlay access between the terminal and the CS core without requiring specific enhancements or support in the network it traverses. This provides a terminal with a 'virtual' connection to the core network already deployed by an operator. The terminal and network thus reuse most of the existing mechanisms, deployment and operational aspects.

Q15. How does Intra E-UTRAN Handover is performed?

Ans: Intra E-UTRAN Handover is used to hand over a UE from a source eNodeB to a target eNodeB using X2 when the MME is unchanged. In the scenario described here Serving GW is also unchanged. The presence of IP connectivity between the Serving GW and the source eNodeB, as well as between the Serving GW and the target eNodeB is assumed.

The intra E-UTRAN HO in RRC_CONNECTED state is UE assisted NW controlled HO, with HO preparation signalling in E-UTRAN.

Q16. Advantage and disadvantage of Cyclic Prefix

Ans:

ADVANTAGE:

• It makes an OFDM signal insensitive to time dispersion as long as the span of the time dispersion does not exceed the length of the cyclic prefix.
• As a repetition of the end of the symbol, it allows the linear convolution of a frequency-selective multipath channel to be modelled as circular convolution, which in turn may be transformed to the frequency domain using a discrete Fourier transform. This approach allows for simple frequency-domain processing, such as channel estimation and equalization.

DISADVANTAGE:

• Only a fraction Tu /(Tu+TCP) of the received signal power is actually utilized by the OFDM demodulator, implying a corresponding power loss in the demodulation.
• CP insertion also implies a corresponding loss in terms of bandwidth as the OFDM symbol rate is reduced without a corresponding reduction in the overall signal bandwidth.

Q17. What is CS Fallback in LTE?

Ans: LTE technology supports packet based services only, however 3GPP does specifies fallback for circuit switched services as well. To achieve this LTE architecture and network nodes require additional functionality, this blog is an attempt to provide overview for same.
In LTE architecture, the circuit switched (CS) fallback in EPS enables the provisioning of voice and traditional CS-domain services (e.g. CS UDI video/ SMS/ LCS/ USSD). To provide these services LTE reuses CS infrastructure when the UE is served by E UTRAN.

Q18. What is SON & how does it work in LTE?

Ans: Self-configuring, self-optimizing wireless networks is not a new concept but as the mobile networks are evolving towards 4G LTE networks, introduction of self configuring and self optimizing mechanisms is needed to minimize operational efforts. A self optimizing function would increase network performance and quality reacting to dynamic processes in the network.
This would minimize the life cycle cost of running a network by eliminating manual configuration of equipment at the time of deployment, right through to dynamically optimizing radio network performance during operation. Ultimately it will reduce the unit cost and retail price of wireless data services.

Q19. How does LTE Security works?

Ans: The following are some of the principles of 3GPP E-UTRAN security based on 3GPP Release 8 specifications:

• The keys used for NAS and AS protection shall be dependent on the algorithm with which they are used.
• The eNB keys are cryptographically separated from the EPC keys used for NAS protection (making it impossible to use the eNB key to figure out an EPC key).
• The AS (RRC and UP) and NAS keys are derived in the EPC/UE from key material that was generated by a NAS (EPC/UE) level AKA procedure (KASME) and identified with a key identifier (KSIASME).
• The eNB key (KeNB) is sent from the EPC to the eNB when the UE is entering ECM-CONNECTED state (i.e. during RRC connection or S1 context setup).

Q20. How does Network Sharing works in LTE?

Ans: 3GPP network sharing architecture allows different core network operators to connect to a shared radio access network. The operators do not only share the radio network elements, but may also share the radio resources themselves.

Q21. What is LTE architecture?

Ans: The evolved architecture comprises E-UTRAN (Evolved UTRAN) on the access side and EPC (Evolved Packet Core) on the core side.
